Industrial IoT Gateway — 10-Layer Redesign for Field Reliability
A field gateway maker traced recurring thermal-cycling failures to a stack-up problem and worked with Copperline to redesign for reliability.
- Industry
- Industrial IoT
- Layer Count
- 10
- Production Volume
- 6,500 units/year
Challenge
An industrial IoT gateway manufacturer was seeing a field failure pattern concentrated in outdoor deployments with heavy thermal cycling — intermittent connectivity failures traced back to microcracking in specific via locations after repeated expansion and contraction, on an existing 10-layer board.
Approach
Copperline's engineering team reviewed the failed units alongside the original stack-up and identified an aspect-ratio issue in the affected via locations combined with a dielectric material not well suited to the temperature range the units actually saw in the field. A revised 10-layer stack-up with adjusted via aspect ratios and a higher-Tg dielectric was proposed and validated through accelerated thermal-cycling testing before full production cutover.
Outcome
Post-redesign units have run through two full outdoor deployment seasons with zero recurrence of the failure pattern. The gateway now ships at 6,500 units/year with the revised stack-up as the qualified baseline design.
